- High quality imaging with 8 MP resolution. Efficient H.265 compression technology
- Clear imaging even with strong back lighting due to 120 dB WDR. Water and dust resistant (IP67)
- EXIR 2.0: advanced infrared technology with long IR range
- Built-in microphone for real-time audio security
- Support on-board storage up to 256GB (SD card slot)
Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Signal System: PAL/NTSC
Min. Illumination: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with Light
Shutter time: 1/3 s to 1/100,000 s
Slow shutter: Support
Lens: 2.8 mm, horizontal FOV 108°, vertical FOV 60°, diagonal FOV 127°
Lens Mount: M12
Day& Night: Auto
Wide Dynamic Range: 120 dB
Digital noise reduction: 3D DNR
Compression Standard
Video Compression:H.265 /H.265/H.264 /H.264/MJPEG
Video bit rate:32Kbps~16Mbps
Max. Image Resolution: 3840 × 2160 @ 30fps
Image Enhancement: BLC/3D DNR/HLC/ROI
Image Settings: Saturation, brightness, contrast, sharpness, AGC,
white balance adjustable by client software or web browser
ROI: Support 1 fixed region for main stream and sub-stream separately
Network
Network Storage: microSD/SDHC/SDXC card (256G), local storage and NAS (NFS,SMB/CIFS), ANR
General Function: One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Interface
Communication Interface: 1 RJ45 10M / 100M Ethernet interfaceReset Button: Yes
Smart Feature-set
Behavior Analysis: Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
Line Crossing Detection: Cross a pre-defined virtual line
Intrusion Detection: Enter and loiter in a pre-defined virtual region
Unattended Baggage: Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Object Removal: Objects removed from the pre-defined region, such as the exhibits on display.
General
Power Supply:12 VDC ± 25%, 5.5 mm coaxial power plug ,PoE (802.3af, class 3)
Weather Proof:IP67
